Product Description of 3D Dynamic Focusing Fiber Laser Marking Machine for Curved Surfaces
3d dynamic focusing fiber laser marking machine details
Fiber laser marking machine accessories
Laser cutting curved surfaces technical parameter
| Model | LS-YLP-20L/30L/50L |
|---|---|
| Laser Power | 20W 30W 50W |
| Laser type | Fiber(CO2 or UV is available) |
| Purpose | Marking and Engraving |
| Wavelength | 1064nm |
| Galvanometer | Dynamic Auto focus 3D scan head system |
| Marking Area | 70*70mm 110*110mm,150*150mm 200x200mm,300*300mm 400*400mm (optional) |
| Marking Depth | 0.03-0.5mm |
| Controller | Computer with marking software |
| Graphic format supported | JPG,BMP,DXF,PLT,STL |
| Working voltage | AC220V 50HZ ,AC110V 60HZ |
| Cooling type | Air cooling |
| Operating parameter | 0-40℃ |
| Laser module life | >70,000-100,000 hours |
| Warranty | 24 months |
| G.W. | 145KG |
| Package(L*W*H) | 75*68*154cm |
| Product description | System operation | Windows PC |
|---|---|---|
| Software | MM3D laser marking controler | |
| Control card | PMC2e/UMC4 | |
| Board interface | PCle/USB | |
| Language | International Language | |
| External axis control | XY platform control, Z-axis liting, rotation axis | |
| Scanhead | Aperture | 10mm |
| The diameter of the input spot | 6.0~8mm | |
| Dynamic Z-axis speed | >1400mm/s | |
| XY-axis scan speed | >7000mm/s | |
| Scan lens | Quartz field lens | |
| Operating temperature | 25+10C | |
| Appendix | Support 2D precision correction file and the focal error correction file | |
| Product application | Surface, Sphere, Inclined surface | |
| Deep sculpture and cutting | ||
| Extended function | Large picture splicing, Customized software development, CCD Visual Marking, Spiral dialing | |
3d dynamic focusing fiber laser marking machine data reference
| Scan lens data reference | |||||
|---|---|---|---|---|---|
| Marking range (mm) |
Fiber | UV | |||
| Variable focal length range(mm) Variable focal length total (mm) | Variable focal lengthrange(mm) | Variable focal length total (mm) | |||
| 70*70 | 100-117 17 | 131-140 | 9 | ||
| 110*110 | 168-195 27 | 201-218 | 17 | ||
| 150*150 | 231-272 41 | 307-350 | 43 | ||
| 200*200 | 303-392 89 | 367-437 | 70 | ||
| 300*300 | 413-602 189 | 469-596 | 127 | ||
| 400*400 | 96-1036 440 | ||||
